Day to day activities for a Data Engineer with the AI agents

As introduced in the methodology chapter, the data engineers have a lot to address during the life of a data streaming processing project. This chapter maps those activities to the tools within this repository and the agent skills to potentially use within an AI harness.

This chapter is structured by use cases, and the other descriptions in this documentation may go deeper in the command references.

The acronymes used are:

Acronym/Term	Definition
DSP	Data Streaming Project. Groups Kafka, schema registry, Flink processing and Tableflow

Components Involved

A Confluent Cloud Data Streaming Processing project includes the following components:

• Some are managed by Site Reliability Engineers using infrastructure as code.
• Most of the streaming logic implementations is done using Flink, and other queries mechanisms

Create a DSP Project

• Create a project directory:

  mkdir $HOME/dsp-project
  cd $HOME/dsp-project
  git init


• Start your harness CLI or IDE (IBM Bob). If you use an IDE, load the project in your workspace.

• Execute a prompt in your agent harness or run a command:

  Agent prompt	using /dbt-project create a dbt project under current folder. use data as a product structure
  Command	uv run sl-dbt init $HOME/dsp-project --type data-product --profile cc_flink

Define / update user's .dbt/profiles.yml

The .dbt/profiles.yml is created when running dbt init. But it is possible to reuse connection definition without running this command each time. As an example the profile.yml include the `cc_flink connection as:

cc_flink:
  outputs:
    dev:
      cloud_provider: aws
      cloud_region: us-west-2
      compute_pool_id: lfcp-1
      dbname: j9r-kafka
      environment_id: '{{ env_var(''ENVIRONMENT_ID'') }}'
      execution_mode: streaming_query
      flink_api_key: '{{ env_var(''FLINK_API_KEY'') }}'
      flink_api_secret: '{{ env_var(''FLINK_API_SECRET'') }}'
      organization_id: '{{ env_var(''ORGANIZATION_ID'') }}'
      statement_label: dbt-confluent
      statement_name_prefix: dbt-
      threads: 1
      type: confluent
  target: dev

This can be reused between project, as each dbt_project.yml references profile: 'cc_flink'

Manage Flink elements

Add data product

Data product will help to group Flink pipelines related to the same appplication, same analytics metrics.

• Execute a prompt in your agent harness or run a command:

  Agent prompt	add a data analytics product named crm in this project
  Command	`uv run sl-dbt sl-dbt add-data-product .$HOME/dsp-project crm

Add table to a data product

Agent prompt	add a table to deduplicate raw customer in sources, name it: src_customers for the crm data product
Command	`uv run sl-dbt sl-dbt add-table .$HOME/dsp-project crm --table-type source

Create raw topics

To prepare dbt run, the sources is referencing exising kafka topics. Sometime, for demonstration purpose, or the topic is not yet available in the kafka cluster.

Agent prompt	add a raw topic named raw_customers in the project as raws
Command	uv run sl-dbt add-raw-topic $HOME/dsp-project raw_customers

Then deploy the raw table

Agent prompt	add a raw topic named raw_customers in the project as raws
Command	uv run flink-sql-deploy --sql-dir $HOME/dsp-project/pipelines/raws deploy

Create a Flink Statement

The steps may looks like:

1. Create the first version of the query in Confluent Cloud Workspace. This is relevant to get access to real data and be able to discover - prepare - validate the SQL query syntax and results. In this form data engineers use SELECT ... statement. As an example we want to deduplicate some raw_customers data.

   WITH ranked_customers AS (
       SELECT
           *,
           ROW_NUMBER() OVER (
               PARTITION BY customer_id
               ORDER BY updated_at DESC
           ) AS rn
       FROM {{ source('raws', 'raw_customers') }}
       WHERE customer_id IS NOT NULL
   )
   SELECT
       customer_id,
       updated_at,
       first_name,
       last_name,
       email,
       created_at
   FROM ranked_customers
   WHERE rn = 1


2. Save to disk and visible in IDE

   dsp-project
   ├── docs
   ├── IaC
   ├── pipelines
   ├── tmp-flink
   │   └── src_customers.yml


3. Run the migration to dbt from this file:

   uv run
