RAG System¶

The Retrieval-Augmented Generation (RAG) system enables semantic search across the knowledge base using vector embeddings. The core implementation resides in the agent_core library, with the backend API providing HTTP endpoints.

Architecture¶

Classical RAG architecture supported by the Code.

Module Structure¶

The RAG service is implemented in agent_core/services/rag/:

agent_core/
└── services/
    └── rag/
        ├── __init__.py           # Public exports
        ├── service.py            # RAGService, SearchResult, IndexingResult
        ├── document_loader.py    # DocumentLoader, LoadedDocument
        └── text_splitter.py      # RecursiveTextSplitter, TextChunk

Components¶

Document Loader¶

Loads document content from various sources (agent_core/services/rag/document_loader.py):

from agent_core.services.rag.document_loader import DocumentLoader, LoadedDocument

loader = DocumentLoader(timeout=30.0)
documents = await loader.load(uri, document_type)

Supported sources:

Type	Description	Example URI
markdown	Local or remote markdown files	`file:///path/to/doc.md` or `https://...`
website	Web page content (HTML parsed to markdown)	`https://example.com/page`
folder	Directory of markdown files	`/path/to/docs/`

The loader returns a list of LoadedDocument objects containing:

class LoadedDocument(BaseModel):
    content: str           # Extracted text content
    document_id: str       # Unique document identifier
    content_hash: str      # SHA256 hash for change detection
    source_uri: str        # Original source URI
    title: Optional[str]   # Extracted title

Frontmatter Support¶

Markdown files can include YAML frontmatter for metadata:

---
title: Configuration Guide
document_id: config-guide-v1
source_url: https://docs.example.com/config
---

# Configuration Guide

Content here...

Text Splitter¶

Splits documents into chunks for embedding (agent_core/services/rag/text_splitter.py):

from agent_core.services.rag.text_splitter import RecursiveTextSplitter, TextChunk

splitter = RecursiveTextSplitter(
    chunk_size=1000,       # Target chunk size in characters
    chunk_overlap=200      # Overlap between chunks
)

chunks: list[TextChunk] = splitter.split_text(content, metadata)

The recursive splitter attempts to split on natural boundaries:

Paragraphs (\n\n)
Lines (\n)
Sentences (.)
Words ()
Characters (fallback)

Each chunk is a TextChunk object:

class TextChunk(BaseModel):
    content: str        # Chunk text
    start_index: int    # Character offset in original content
    chunk_index: int    # Position in the document
    metadata: dict      # Inherited metadata

Embedding Model¶

Uses sentence-transformers for local embedding generation:

Model: all-MiniLM-L6-v2
Runs entirely locally (no external API calls)
Produces 384-dimensional vectors
Optimized for semantic similarity

Vector Store¶

ChromaDB provides persistent vector storage.

Configuration via environment variables:

Variable	Default	Description
`CHROMA_PERSIST_DIRECTORY`	`./data/chroma`	ChromaDB storage path
`CHROMA_COLLECTION_NAME`	`knowledge_base`	Vector collection name
`CHUNK_SIZE`	`1000`	Text chunk size
`OVERLAP`	`200`	Chunk overlap
`EMBEDDING_MODEL`	`all-MiniLM-L6-v2`	Sentence transformer model

Features:

Cosine similarity for search (configured via hnsw:space)
Metadata filtering by category, tags, knowledge_id
Persistent storage across restarts
Automatic collection management

Code Integration¶

Using RAGService Directly¶

from agent_core.services.rag.service import RAGService, get_rag_service

# Singleton access (recommended for applications)
rag = get_rag_service()

# Or manual initialization with custom settings
rag = RAGService(
    persist_directory="./data/chroma",
    collection_name="knowledge_base",
    chunk_size=1000,
    chunk_overlap=200,
    embedding_model="all-MiniLM-L6-v2"
)

Indexing Documents¶

from agent_core.services.rag.service import get_rag_service, IndexingResult

rag = get_rag_service()

# Index a single document
result: IndexingResult = await rag.index_knowledge(
    knowledge_id=123,
    title="OAuth Guide",
    uri="/path/to/document.md",
    document_type="markdown",  # or "website" or "folder"
    category="security",
    tags="auth,oauth,security"
)

print(f"Success: {result.success}")
print(f"Chunks indexed: {result.chunks_indexed}")
print(f"Content hash: {result.content_hash}")
if result.error:
    print(f"Error: {result.error}")

IndexingResult Model¶

class IndexingResult(BaseModel):
    success: bool
    chunks_indexed: int
    content_hash: str
    error: Optional[str] = None

Searching¶

from agent_core.services.rag.service import get_rag_service, SearchResult

rag = get_rag_service()

results: list[SearchResult] = await rag.search(
    query="How to implement OAuth?",
    n_results=5,
    category="security",           # Optional filter
    knowledge_ids=[1, 3, 7]        # Optional: search within specific documents
)

for result in results:
    print(f"Score: {result.score:.2f}")
    print(f"Title: {result.title}")
    print(f"Content: {result.content[:200]}...")

SearchResult Model¶

class SearchResult(BaseModel):
    content: str
    knowledge_id: int
    title: str
    uri: str
    score: float
    chunk_index: int

Removing from Index¶

rag = get_rag_service()

success = await rag.remove_knowledge(knowledge_id=123)

Getting Collection Statistics¶

rag = get_rag_service()

stats = rag.get_collection_stats()
# Returns: {
#   "total_chunks": 150,
#   "unique_knowledge_items": 12,
#   "collection_name": "knowledge_base",
#   "embedding_model": "all-MiniLM-L6-v2"
# }

Using RAGAgent for AI Responses¶

The RAGAgent combines RAG search with LLM generation:

from agent_core.agents.rag_agent import RAGAgent
from agent_core import LLMConfig

# Configure LLM
config = LLMConfig(
    provider="openai",
    model="gpt-4",
    api_key="your-api-key"
)

# Create RAG agent
agent = RAGAgent(
    llm_config=config,
    n_results=5  # Number of context chunks to retrieve
)

# Execute query with RAG
response = await agent.execute(
    query="How do I configure database connections?",
    conversation_history=[
        {"role": "user", "content": "previous message"},
        {"role": "assistant", "content": "previous response"}
    ],
    context={"entities": {"topic": "database", "keywords": ["config", "connection"]}}
)

print(response.message)           # LLM-generated response
print(response.context_used)      # Retrieved documents with scores
print(response.agent_type)        # "rag"

AgentResponse Structure¶

@dataclass
class AgentResponse:
    message: str                      # LLM response text
    context_used: list[dict] = []     # RAG context with title, uri, score, snippet
    model: str = ""                   # Model used
    provider: str = ""                # Provider used
    agent_type: str = ""              # "rag"
    metadata: dict = {}               # search_query, results_count

FastAPI Integration¶

The backend exposes RAG functionality via dependency injection:

from fastapi import APIRouter, Depends
from agent_core.services.rag.service import get_rag_service, RAGService

router = APIRouter()

def get_rag() -> RAGService:
    """Dependency to get the RAG service."""
    return get_rag_service()

@router.post("/search")
async def search(
    query: str,
    rag: RAGService = Depends(get_rag)
):
    results = await rag.search(query)
    return {"results": results}

API Endpoints¶

Index Knowledge Item¶

POST /api/v1/rag/index/{knowledge_id}

Response:

{
  "success": true,
  "knowledge_id": 1,
  "chunks_indexed": 15,
  "content_hash": "abc123..."
}

Index All Items¶

POST /api/v1/rag/index-all?status=active

Indexes all knowledge items matching the filter. Returns summary with per-item results.

Remove from Index¶

DELETE /api/v1/rag/index/{knowledge_id}

Removes all chunks for a knowledge item from the vector store.

Semantic Search (POST)¶

POST /api/v1/rag/search
Content-Type: application/json

{
  "query": "How to configure the database connection?",
  "n_results": 5,
  "category": "Engineering"
}

Response:

{
  "query": "How to configure the database connection?",
  "results": [
    {
      "content": "Database configuration is managed via environment...",
      "knowledge_id": 3,
      "title": "Configuration Guide",
      "uri": "/docs/config.md",
      "score": 0.87,
      "chunk_index": 2
    }
  ],
  "total_results": 5
}

Semantic Search (GET)¶

Convenience endpoint for simple searches:

GET /api/v1/rag/search?q=database+configuration&n=5&category=Engineering

Collection Statistics¶

GET /api/v1/rag/stats

Response:

{
  "total_chunks": 150,
  "unique_knowledge_items": 12,
  "collection_name": "knowledge_base",
  "embedding_model": "all-MiniLM-L6-v2"
}

Search Filtering¶

By Category¶

{
  "query": "authentication",
  "category": "Engineering/Security"
}

By Tags¶

{
  "query": "deployment steps",
  "tags": ["docker", "production"]
}

By Knowledge IDs¶

Search within specific documents:

{
  "query": "error handling",
  "knowledge_ids": [1, 3, 7]
}

Chunk Metadata¶

Each stored chunk includes metadata:

Field	Description
knowledge_id	Source knowledge item ID
title	Document title
uri	Source URI
document_type	markdown, folder, or website
category	Document category
tags	Associated tags
chunk_index	Position in document
start_index	Character offset
indexed_at	Indexing timestamp
fetched_at	Content fetch timestamp

Scoring¶

Search results include a similarity score (0-1):

0.9+: Highly relevant match
0.7-0.9: Good match
0.5-0.7: Partial match
<0.5: Weak match

The score represents cosine similarity between query and chunk embeddings.

Storage Location¶

ChromaDB data persists in:

backend/data/chroma/
├── chroma.sqlite3         # Metadata database
└── {collection-uuid}/     # Vector data
    ├── data_level0.bin
    ├── header.bin
    ├── length.bin
    └── link_lists.bin

Knowledge Status Integration¶

Indexing automatically updates the knowledge item:

Action	Status Change	Fields Updated
Index success	`pending` → `active`	`content_hash`, `last_fetched_at`, `indexed_at`
Index failure	`pending` → `error`	`status` only
Re-index	Unchanged	`content_hash`, `last_fetched_at`, `indexed_at`

Testing¶

The RAG system includes comprehensive tests (tests/ut/test_rag.py):

# Run RAG tests
uv run pytest tests/ut/test_rag.py -v

Test Coverage¶

Empty collection queries
Indexing with valid markdown files
Search after indexing
Category filtering
Index removal
Bulk indexing (index-all)
Status and hash updates
Error handling for invalid files

Test Example¶

@pytest.mark.asyncio
async def test_rag_search_after_indexing(client, sample_markdown_file):
    # Create and index a knowledge item
    create_response = await client.post(
        "/api/knowledge/",
        json={
            "title": "Search Test Document",
            "document_type": "markdown",
            "uri": f"file://{sample_markdown_file}",
            "category": "SearchTest"
        }
    )
    knowledge_id = create_response.json()["id"]

    await client.post(f"/api/rag/index/{knowledge_id}")

    # Search for content
    search_response = await client.get("/api/rag/search?q=Python+programming&n=3")
    assert search_response.json()["total_results"] > 0

Performance Considerations¶

Chunk Size¶

Smaller chunks: More precise retrieval, more storage
Larger chunks: More context per result, less precision

Default (1000 chars) balances these tradeoffs.

Batch Indexing¶

For initial setup, use index-all endpoint to process documents in batch rather than individual calls.

Embedding Cache¶

Embeddings are computed once during indexing. Queries compute embeddings on-demand (fast for short queries).

Error Handling¶

The RAG service handles errors gracefully:

{
  "success": false,
  "knowledge_id": 1,
  "chunks_indexed": 0,
  "content_hash": "",
  "error": "File not found: /nonexistent/path/file.md"
}

Common errors:

Error	Cause	Resolution
File not found	Invalid file path in URI	Verify the `uri` field points to an existing file
No content to index	Empty document	Add content to the document
ChromaDB error	Storage issue	Check disk space and permissions
